Bijie Foam Sealing Mobile Toilet

The Bijie foam sealing mobile toilet is an environmentally friendly mobile toilet designed based on foam sealing technology. Its core principle is to use a foaming device to generate microbubbles for fecal treatment, offering advantages such as water conservation, odor control, and self-cleaning, making it suitable for scenarios with limited water supply or temporary use.

Technical Principles and Core Functions

The foam sealing mobile toilet uses a foaming device to mix foaming liquid with air in a specific ratio, generating fine and uniform microbubbles. These bubbles cover the surface of the excretory passage, forming a flexible barrier and achieving four core functions:

1. Odor Control: The foam layer acts as a physical barrier, effectively preventing the reverse diffusion of gases from the pipes while reducing the release of odor molecules through adsorption. Its deodorizing effect is significantly better than that of traditional water-flush toilets.
2. Water Conservation Performance: Experiments show that this technology can reduce water consumption to as low as 0.04 liters per use, achieving a water-saving rate of 98%. It reduces liquid consumption by about 80% compared to traditional water-flush methods, making it particularly suitable for water-scarce areas.
3. Self-Cleaning Function: As new foam is continuously generated, old foam carries impurities from fecal matter along the pipes, achieving automatic cleaning and reducing the frequency of manual maintenance.
4. Anti-Clogging Characteristics: The flowability of foam is superior to that of solid substances, and the continuous generation of new foam exerts a pushing effect on the pipes, reducing the risk of clogging and resulting in lower maintenance costs compared to traditional systems.

System Structure and Maintenance Points

The toilet system has a relatively simple structure, with core components including a foaming liquid storage tank, an air pump, a mixing generator, and a control module. Daily maintenance should focus on:

• Regularly replenishing the foaming liquid to ensure stable foam generation;
• Checking the working status of the air pump to avoid a decrease in foam quality due to insufficient air pressure;
• Cleaning the fecal collection device to prevent long-term accumulation from affecting system operation.

Application Scenarios and Cost Advantages

The foam sealing mobile toilet is particularly suitable for scenarios with limited water supply or inadequate drainage conditions, such as temporary event venues, outdoor work areas, and remote regions. Although its initial investment cost is slightly higher than that of traditional mobile toilets, it can significantly save on water and sewage treatment costs during long-term operation, making its overall usage cost more competitive. For example, in large-scale outdoor events, its water-saving feature can greatly reduce logistical support pressure while minimizing the environmental impact of sewage discharge.
