Guigang Mobile Toilet Installation Steps

The installation steps for mobile toilets in Guigang need to be determined according to the specific type, mainly divided into two types: integrated mobile restrooms and simple mobile toilets. The specific procedures are as follows:

Integrated Mobile Restroom Installation Steps

1. Site Preparation

   • Confirm that the installation site has a flat ground and reserve sewage discharge interfaces (direct-discharge types need to be connected to the municipal sewage network, while collection types need to be equipped with sewage tanks or septic tanks).
   • Ensure that external water sources (or built-in water tanks) and power supplies (municipal power or solar power) are in place to avoid interruptions during subsequent construction.

2. Lifting and Positioning

   • Use lifting equipment to hoist the prefabricated integrated box (including steel structure framework, composite panel enclosure, anti-slip floor, etc.) to the target location.
   • Note: During the lifting process, avoid colliding with the box to prevent structural or panel damage.

3. Pipe Connection

   • Connect the sewage pipes of internal sanitary fixtures (such as toilets and washbasins) to the reserved interfaces: direct-discharge types are connected to the municipal sewage network, while collection types are connected to sewage storage devices.
   • Connect the water supply system to external water sources or start the built-in water tank to ensure a stable water supply.

4. Electrical Debugging

   • Turn on the power supply for equipment such as lighting and exhaust fans, and test whether functions such as smart induction flushing and automatic disinfection are working properly.
   • If the equipment is equipped with solar panels, check whether the sun exposure angle meets the charging requirements.

5. Seal Inspection

   • Check whether the sealing strips or sealants at interfaces such as sewage pipes and water tank connections are intact, with a focus on inspecting easily leaking parts such as elbows and tees.
   • Only proceed to the next step after confirming that there is no risk of leakage.

6. Acceptance and Use

   • After cleaning the site, conduct a water test: flush with a small flow to check the smoothness of sewage discharge and flush with a large flow to check for interface leakage.
   • After confirming that there are no abnormalities, it can be put into use.

Simple Mobile Toilet Installation Steps (Requiring Short-Distance Relocation)

1. Using a Relocator

   • Chisel out 20-40mm of the ground floor slab and embed a finished relocator (an elliptical flat pipe with a height of about 60mm), with one end connected to the original sewage pipe and the other end extending to the target location.

2. Ground Treatment

   • Pour a flat ground and apply waterproofing (with a height of about 20mm), lay tiles (with a height of about 30mm), and leave a 3-4cm construction slot for relocator installation.

3. Fixing the Relocator

   • Insert the lower interface into the sewage pipe and backfill with cement slurry, and connect the upper interface to the toilet sewage outlet.
   • Apply PVC special adhesive at the connection and install a sealing ring (to prevent flipping, lubricant can be applied for assistance).

4. Seal Filling

   • Fill and seal the empty space after relocation with cement or waterproof materials to ensure a reasonable pipe slope (a slope of more than 3% is required for relocations exceeding 300mm).

5. Installing the Toilet

   • Align the toilet with the upper interface of the relocator, fix it, and then connect the water inlet hose.
   • Open the water inlet valve and flush to test for sewage discharge and leakage. The relocation distance should be controlled within 100mm-350mm, and should not exceed 400mm at most, otherwise the risk of blockage will increase.

Precautions:

• The installation of an integrated mobile restroom takes several hours and is suitable for emergency or short-term projects without complex water and electricity works.
• For inter-floor drainage modifications, consult with the downstairs occupants and ensure proper waterproofing and trap installation.
