Chuxiong Rural Mobile Toilet Specifications
The specifications of mobile toilets in rural areas of Chuxiong vary depending on the type and functional requirements. Common specifications are as follows:
I. Basic Size Range
A single-stall mobile public toilet covers an area of approximately 1.2㎡ to 1.8㎡, with internal clear dimensions typically being 1.2m to 1.5m in length, 1.0m to 1.2m in width, and a height between 2.2m and 2.5m. For multi-stall mobile public toilets, taking a double-stall as an example, the area covered is about 3㎡ to 4㎡; for three stalls or more, the area increases based on the number of stalls, with each additional stall adding approximately 1.5㎡ to 2㎡ of usable area. The overall length is mostly between 3m and 6m, and the width is usually 1.5m to 2.5m. These specifications are suitable for ordinary public areas and meet basic usage needs.
II. Functional Partition Sizes
Barrier-free toilet stalls must meet the needs of special populations, with internal clear dimensions not less than 1.8m × 1.4m. A barrier-free ramp with a width of more than 0.8m must be installed at the entrance, and sufficient space must be reserved inside the stall for wheelchair rotation. Baby care rooms or third toilets generally have an area of not less than 4㎡ and must be equipped with facilities such as baby changing tables and children's toilets, with a clear width of ≥1.5m to ensure operating space. Such partition designs embody a combination of humanization and functionality, suitable for scenic spots, service areas, and other scenarios.
III. Materials and Structure
The main materials include galvanized pipe columns (80802.5mm), inner-lining galvanized pipes (60401.8mm, 40201.5mm), high-density PVC hanging panels, 3mm Jixiang aluminum-plastic panels, insulation panels, non-slip floors, etc. The main frame of the booth is welded with steel keels, providing strong wind resistance; the roof adopts a waterproof hinge process, covered with asphalt shingles, completely solving the problem of water leakage; the exterior wall is made of high-density PVC hanging panels, and the interior wall is made of aluminum-plastic panels, generally white in color. Water-flush mobile toilets are based on a steel structure, equipped with marble, insulation materials, and basic toilet configurations, with the water outlet system and insulation system being key.
IV. Configuration and Customization
Basic configurations include distribution boxes, power switches, ceiling lights, power sockets, workbenches, air conditioning sockets, and exterior wall decorative lights, etc. Specifications can be customized according to customer needs, with frames available in galvanized steel pipes or channel steels, walls can be made of aluminum alloy decorative louvers, tempered glass, etc., doors and windows can be aluminum alloy sliding windows or frameless floor spring doors, and the interior ceiling can be made of high-strength PVC扣板 (扣板 can be translated as 'buckle panels' or kept as 'kouban' if it's a specific product name in the industry, here I'll use 'buckle panels' for clarity)吊顶 (which means 'suspended ceiling'). Customized services can meet the aesthetic and functional needs of different scenarios.
